Compare Prices

Brazed Plate Heat Exchanger

Plate Heat Exchanger Brazed - Brazed Plate Heat Exchanger Stainless Steel SS316L 3
Brazed Plate Heat Exchanger Stainless Steel SS316L 3"x8" 20 Plates 3/4" MPT 180,000 BTU/hr Hydronic Heating

Built with high quality stainless steel 316L and 99.9% copper, this model produces a counter-current flow to maximize heat efficiency. This product is highly efficient due to the corrugated plates which produce a high, turbulent flow in a true counter-current direction. With their compact size and reduced material content, they can be the most economical heat transfer choice. Product Information and Specifications Stainless Steel 316L/Copper 20 Plates Port Size: 3/4" MPT 130,000 - 180,000 Btu/hr Capacity Floor Heating Capacity: 180,000 Btu/hr Floor Heating GPM (Boiler = 180F / System = 100F-130F): 12.4 GPM / 12.4 GPM Domestic Hot Water Heating Capacity: 130,000 Btu/hr Domestic Hot Water Heating GPM (Boiler = 180F / Pipe 40F-140F): 9 GPM / 3 GPM Min. Operating Temp.: -256F Max. Operating Temp.: 482F Design Pressure: 435psi Test Pressure: 653psi Materials: Stainless Steel 316L, 99.9% Copper Dimensions: 3" x 8" Applications Domestic Hot Water Heating Central Heating Floor Heating Driveway Snow Melting Radiator Heating Heating and Cooling HVAC Installation Solar Heating

  • Brand: AB
  • ASIN: B073ZND46C
  • Part No: BL14-20D
Heat Brazed Exchanger Plate - Duda Energy HX1230:F12 B3-12A 30 Plate Stainless Steel Heat Exchanger with 1/2
Duda Energy HX1230:F12 B3-12A 30 Plate Stainless Steel Heat Exchanger with 1/2" Female NPT Ports Copper Brazed, 2.9" Height, 2.9" Width, 7.5" Length

Stainless steel plate heat exchangers . Brazed with 99.9+ percent Pure copper by Duda Energy . Plate heat exchangers have significantly good heat transfer rates because they use metal plates which have high heat conductivity rates and the plates are extremely thin. The plate heat exchangers also achieve high amounts of heat transfer through Convective forces with both working fluids. With large temperature differentials, great amounts of heat transfer can be achieved using a plate heat exchanger.This is an extremely popular unit for wood burning furnaces, radiant floor systems, refrigerant systems, straight vegetable oil conversions, beer chilling, air conditioning system and solar water heating systems. It will work for any application in which the desired result is for two fluids (liquid or gas) to exchange heat. Fluid a passes from the port on the left of the heat exchanger through every other channel created by the plates to the opposite end port on the left of the heat exchanger (looking at it the long way). fluid b passes from the port on the right through the other channels created by the plates and comes out the other port on the right side. The fluids are essentially touching each other through the plates and heat is transferred from the hot fluid to the cold fluid. (But...

  • Brand: Duda Energy
  • ASIN: B003EBSUEA
  • UPC: 840194103299
  • Part No: HX1230:F12
Plate Brazed Exchanger Heat - Brazed Plate Heat Exchanger Stainless Steel SS316L 5
Brazed Plate Heat Exchanger Stainless Steel SS316L 5"x12" 20 Plates 1 1/4" MPT 330,000 BTU/hr Hydronic Heating

Built with high quality stainless steel 316L and 99.9% copper, this model produces a counter-current flow to maximize heat efficiency. This product is highly efficient due to the corrugated plates which produce a high, turbulent flow in a true counter-current direction. With their compact size and reduced material content, they can be the most economical heat transfer choice. Product Information and Specifications Stainless Steel 316L/Copper 20 Plates Port Size: 1 1/4" MPT 170,000 - 330,000 Btu/hr Capacity Floor Heating Capacity: 330,000 Btu/hr Floor Heating GPM (Boiler = 180F / System = 100F-130F): 11 GPM / 11 GPM Domestic Hot Water Heating Capacity: 250,000 Btu/hr Domestic Hot Water Heating GPM (Boiler = 180F / Pipe 40F-140F): 15 GPM / 5 GPM Driveway Snow Melting Capacity: 170,000 Btu/hr Driveway Snow Melting GPM (Boiler = 180F / 50% Glycol = 110F-140F): 11 GPM / 12 GPM Min. Operating Temp.: -256F Max. Operating Temp.: 482F Design Pressure: 435psi Test Pressure: 653psi Materials: Stainless Steel 316L, 99.9% Copper Dimensions: 5" x 12" Applications Domestic Hot Water Heating Central Heating Floor Heating Driveway Snow Melting Radiator Heating Heating and Cooling HVAC Installation Solar Heating

  • Brand: AB
  • ASIN: B073ZNGL48
  • Part No: BL26C-20D
Exchanger Heat Plate Brazed - Brazed Plate Heat Exchanger Stainless Steel SS316L 4
Brazed Plate Heat Exchanger Stainless Steel SS316L 4"x12" 30 Plates 350,000 BTU/hour Hydronic Heating

Built with high quality stainless steel 316L and 99.9% copper, these plate heat exchangers produce a counter-current flow to maximize heat efficiency. This domestic hot water heat exchanger is highly efficient due to the corrugated plates which produce a high, turbulent flow in a true counter-current direction. With their compact size and reduced material content, they can be the most economical heat transfer choice. Product Information and Specifications Stainless Steel 316L/Copper 30 Plates Port Size: 1" MPT 250,000 - 330,000 Btu/hr Capacity Floor Heating Capacity: 330,000 Btu/hr Floor Heating GPM (Boiler = 180F / System = 100F-130F): 22.4 GPM / 22.4 GPM Domestic Hot Water Heating Capacity: 250,000 Btu/hr Domestic Hot Water Heating GPM (Boiler = 180F / Pipe 40F-140F): 17 GPM / 5 GPM Driveway Snow Melting Capacity: 250,000 Btu/hr Driveway Snow Melting GPM (Boiler = 180F / 50% Glycol = 110F-140F): 17 GPM / 19 GPM Min. Operating Temp.: -256F Max. Operating Temp.: 482F Design Pressure: 435psi Test Pressure: 653psi Materials: Stainless Steel 316L, 99.9% Copper Dimensions: 4" x 12" Boiler Plate Heat Exchanger Applications Domestic Hot Water Heating Central Heating Floor Heating Driveway Snow Melting Radiator Heating Heating and Cooling HVAC Insta...

  • Brand: AB
  • ASIN: B073ZNLYTC
  • Part No: BL26-30D
Plate Exchanger Brazed Heat - Mophorn Plate Heat Exchanger 5
Mophorn Plate Heat Exchanger 5" x 12" 50 Plate Water to Water Heat Exchanger Stainless Steel Heat Exchanger 1" MPT Ports

The brazed plate heat exchanger has a simple operating principle. Based on the plate and nozzle orientation, each fluid passes through alternative channels within the heat exchanger. An extremely high heat transfer coefficient is attained due to the flow characteristics in each channel. A specially design and test result in higher heat transfer and reduction of the amount of deposits inside the unit. Our Water To Water Brazed Plate Heat Exchangers are used for transferring heat from one hot water source to another without mixing the two different water sources. They are good for preheating water to water heaters and for transferring heat from an outdoor furnace or solar system to an indoor boiler. Other uses for them include transferring heat from hot oil or cooling milk off a milk pipeline. Superiority "Herring bone" plate pattern increases heat transfer area and improves efficiency. Compact design allows for more flexibility in installation. Heavy-gauge top and bottom plates protect the unit from corrosion and accidental damage. Applications The 50-plate brazed plate heat exchangers are ideal for using with outdoor wood furnaces/boilers, radiant floor heating projects, plumbing systems, snowmelt systems, swimming pools, domestic water applications, HVAC and refrigeration system...

  • Color: 50 Plate
  • Brand: Mophorn
  • ASIN: B079HSXZ4T
  • UPC: 719034906249
  • Part No: Plate Heat Exchanger
Brazed Exchanger Heat Plate - 20-plates Brazed Plate Stainless Steel Heat Exchanger, 1
20-plates Brazed Plate Stainless Steel Heat Exchanger, 1" mnpt ports, Output: up to 250,000 BTU/hr

20-plates Brazed Stainless Steel Plate Heat Exchanger - Unit Dimensions: 4-1/4"x12" - 1" mnpt ports - 316L Stainless Steel - Copper Brazed - Flow Rate: 40 GPM max - Design pressure 435 psi - Design Temperature -256°F / 437°F

  • Brand: Brazetek
  • ASIN: B00496OJZS
  • Part No: BT4x12-20
Heat Brazed Exchanger Plate - 350,000 BTU/hr: 30-Plate Heat Exchanger, 1
350,000 BTU/hr: 30-Plate Heat Exchanger, 1" MNPT ports, 4-1/4" x 12"

Brazetek Plate Heat Exchanger is designed for use in a variety of liquid-to-liquid heat transfer applications, where a reliable, efficient and compact heat exchanger is needed. Specs: Flow Rate: 40 GPM max. Connections: 1" Male Threaded Dimensions: 4.25" x 12.12" x 3.17" Max BTU output: up to 350,000 BTU/hr

  • Brand: Brazetek
  • ASIN: B00496OK2A
  • Part No: BT4x12-30
Brazed Heat Plate Exchanger - DY19BRIGHT Stainless Steel 80 Plate Water to Water Brazed Plate Heat Exchanger 1/2
DY19BRIGHT Stainless Steel 80 Plate Water to Water Brazed Plate Heat Exchanger 1/2" MPT Ports Home Brewing Beer Brazed plate type water US Stock

Main Application Chillers Waste heat recovery Cooling and heatingof oils Heat pump unit Heating and cooling of compressed gas Boiler/Steam Refrigeration Heating and cooling of high-purity water in areas like medical care, food,electronics and etc Other industrail applications 80-Plate brazed plate heat exchanger 80 Plates dimensions: 190*76*185mm Inlet/Outlet sizes: 1/2 inch threaded Designed Pressure ( MPa ) : 1.0 Min working temperature (c). t 180 Max working temperature ('C) : 200 Maximum Number of Plates:80 Heat transfer area per plate (m') : 0.012 Volume per channel (L) : 0.016 Monolithic channel cross section area: (m') : 0. 000148 Weight: 4kg

  • Color: Orange
  • Brand: DY19BRIGHT
  • ASIN: B07RY6SX9D
  • UPC: 692232762872
 - 30 Plate Water to Water Brazed Plate Heat Exchanger 1
30 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets

Brazed Plate Heat Exchanger

 - 20 Plate Water to Water Brazed Plate Heat Exchanger 1
20 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets

Brazed Plate Heat Exchanger

 - 10 Plate Water to Water Brazed Plate Heat Exchanger 1
10 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets

Brazed Plate Heat Exchanger

 - 20 Brazed Plate Heat Exchanger, 40,000 BTU
20 Brazed Plate Heat Exchanger, 40,000 BTU

Brazed Plate Heat Exchanger

 - 30 Brazed Plate Heat Exchanger, 60,000 BTU
30 Brazed Plate Heat Exchanger, 60,000 BTU

Brazed Plate Heat Exchanger

 - 40 Brazed Plate Heat Exchanger, 75,000 BTU
40 Brazed Plate Heat Exchanger, 75,000 BTU

Brazed Plate Heat Exchanger

 - 40 Plate Water to Water Brazed Plate Heat Exchanger 1
40 Plate Water to Water Brazed Plate Heat Exchanger 1" MPT Ports w/ Brackets

Brazed Plate Heat Exchanger

 - 40 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets
40 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets

Brazed Plate Heat Exchanger

 - Used 60/80/100 Plate Brazed Plate Heat Exchanger NPT MPT Heavy 99.9% pure copper
Used 60/80/100 Plate Brazed Plate Heat Exchanger NPT MPT Heavy 99.9% pure copper

Brazed Plate Heat Exchanger

  • Category: Furnaces & Central Heating Systems
 - 30 Plate Water to Water Brazed Plate Heat Exchanger 1
30 Plate Water to Water Brazed Plate Heat Exchanger 1" MPT Ports w/ Brackets

Brazed Plate Heat Exchanger

  • Category: Furnaces & Central Heating Systems
 - 50-Plate 3x8 Water to Water Brazed Plate Heat Exchanger, 3/4
50-Plate 3x8 Water to Water Brazed Plate Heat Exchanger, 3/4" MPT, 316L St Steel

Brazed Plate Heat Exchanger

  • Category: Hose & Tubing
 - 20 Plate Water to Water Brazed Plate Heat Exchanger 1/2
20 Plate Water to Water Brazed Plate Heat Exchanger 1/2" MPT Port Heating System

Brazed Plate Heat Exchanger

  • Category: Furnaces & Central Heating Systems
 - 20-100 Plate Water to Water Brazed Plate Heat Exchanger 1~1.25'' MPT Ports USA
20-100 Plate Water to Water Brazed Plate Heat Exchanger 1~1.25'' MPT Ports USA

Brazed Plate Heat Exchanger

  • Category: Furnaces & Central Heating Systems
 - 50 Plate Water to Water Brazed Plate Heat Exchanger 1
50 Plate Water to Water Brazed Plate Heat Exchanger 1" FPT Ports w/ Brackets

Brazed Plate Heat Exchanger

  • Category: Water Heater Parts & Accs
 - 20 Plate Heat Exchanger W/Brackets Furnace Water to Water Brazed  Wood Boiler
20 Plate Heat Exchanger W/Brackets Furnace Water to Water Brazed Wood Boiler

Brazed Plate Heat Exchanger

  • Category: Furnaces & Central Heating Systems
 - 10-Plate 3x8 Water to Water Brazed Plate Heat Exchanger, 3/4
10-Plate 3x8 Water to Water Brazed Plate Heat Exchanger, 3/4" MPT, 316L St Steel

Brazed Plate Heat Exchanger

  • Category: Hose & Tubing
